| Price | $6~$1000 |
| MOQ | 1000 |
| Delivery Time | 4~6weeks |
| Brand | HuaXin |
| Place of Origin | China |
| Certification | ISO14001/ ISO9001/IATF16949 |
| Model Number | HX139RAN23A |
| Packaging Details | blister+foam box+bubble bag+inside carton+master carton |
| Payment Terms | T/T |
| Supply Ability | 500K pcs per month |
| Place of Origin | China | Display Technology | round Amoled |
| Brightness | 300C/D | Size | 1.39 inch |
| Packaging Details | blister+foam box+bubble bag+inside carton+master carton | View angle | all |
| Model Number | HX139RAN23A | interface | 20pins MIPI |
| Supply Ability | 500K pcs per month | Certification | ISO14001/ ISO9001/IATF16949 |
| Name | circular Amoled display | Brand Name | HuaXin |
| Payment Terms | T/T | Driving IC | RM69080 |
| Price | $6~$1000 | Delivery Time | 4~6weeks |
| Minimum Order Quantity | 1000 | Resolution | 400X400 |
| Attribute | Value |
|---|---|
| Display Technology | Round AMOLED |
| Size | 1.39 inch |
| Name | Circular AMOLED Display |
| Resolution | 400×400 |
| Interface | 20pins MIPI |
| View Angle | All |
| Brightness | 300C/D |
| Driving IC | RM69080 |
| Part NO. | HX139RAN23A |
|---|---|
| Display Technology | AMOLED |
| Diagonal Screen Size | 1.39 inch round OLED |
| Resolution | 400×400 |
| Viewing Angle | All |
| Operation Temperature | -20 ~ +70 ℃ |
| Active Area (mm) | 35.4×35.4mm |
| Panel Size (mm) | 38.6×40.5×0.7MM |
| Brightness (cd/m²) | 300cd/M² |
| Interface | MIPI |
| Pin Quantity | 20 PINS |
| Contrast Ratio | 10000:1 |
| Driving IC | RM69080 |
| Touch Panel | / |
AMOLED is more expensive than LCD and TFT, has a shorter lifetime than LCD and TFT, and has lower peak brightness in sustained use.
Factory Location: Inland city with cost-effective operations
Equipment: Most advanced new equipment ensuring stable quality
Processes: Fully automatic equipment for efficiency and stable quality
Expertise: Professional engineers with 20+ years experience in LCD field
Customization: Self-design capability for customized products
Company: Huaxin Technology (Enshi) Co., LTD
Location: Hubei, Enshi
Founded: 2009
Specialization: Research, development, production and sales of LCD, LCM, TFT, backlight, OLED
LCD Types: VA, TN, HTN, STN, FSTN, CSTN and other series
LCM Types: COB, TBA, COG, TP, LED backlight and other series
Registered Capital: Twenty million
Employees: 500+
R&D Staff: 10%
QC Staff: 15%
| Annual Production Capacity | 2021 (Current) | 2022 (Goal) | 2023 (Challenge) | 2024 (Challenge) | 2025 (Challenge) | Remark |
|---|---|---|---|---|---|---|
| LCD Production Capacity | 4.5 | 9 | 9 | 9 | 9 | Unit: thousands of logarithms/Day |
| LCM Production Capacity | 70 | 150 | 300 | 450 | 450 | Unit: Thousand piece/Day |
| Backlight Production Capacity | 100 | 200 | 300 | 500 | 500 | Unit: Thousand piece/Day |
| OLED Production Capacity | 10 | 20 | 30 | 40 | 50 | Unit: Thousand piece/Day |
Power Consumption: AMOLED displays consume power on a per-pixel basis, meaning that pixels that display black or dark content consume very little power, while pixels displaying bright or white content consume more power. LCD and LED displays require a constant backlight that consumes power regardless of the displayed content.
Content Dependency: AMOLED displays are more power-efficient for content with dark areas as pixels can be turned off. LCD/LED displays consume constant power as the backlight remains active.
Brightness Control: AMOLED can dynamically adjust pixel brightness for better efficiency in low-brightness scenarios. LCD/LED displays typically have fixed backlight brightness.
Display Size: AMOLED is more power-efficient for smaller displays as consumption scales with pixel count. Larger LCD/LED displays may require more power-hungry backlights.
